Photos
| BEFORE | AFTER |
|---|---|
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
PRODUCT SPECIFICATION
| Type | Laser type CO2 laser (sealed CO2 tube technology; high power continuous electrical discharge) |
| Wavelength | 10 600 nm |
| Mode structure | TEM 00 (transverse electromagnetic) |
| Traffic signal | Articulated 7-mirror arm |
| Beam spot | 0.2 mm (Scanner: 120 ou 250µm) |
| Laser power | Continuous mode: 0.5~40Watts
Pulse mode (normal pulse, super pulse and ultra pulse): 5~22mJ Scanning mode: 5~22mJ |
| Pulse duration | Ultra Pulse mode: 90µs to 900µs;
Super Pulse mode: 1ms to 3.5ms; Pulse mode: 4 to 20ms. |
| Output Frequency | Scanning mode: 500~1000Hz |
| Screen | GUI display colour LCD; simplified
data menu entry |
| Weight and dimensions | 43(l)x48(p)x124(h)cm / 45kg |
